| Brand Name: | RUICOM |
| Model Number: | GDS850 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 100000 pieces/year |
Technical Characteristics
❖ Measurement range: ±30°
❖ Optimal measurement accuracy: ＜0.002°
❖ Ultra-high angular resolution: 0.0005°
❖ Supports key measurement data recording
❖ User self-zero calibration function available
❖ Dual strong magnetic measuring surfaces at the bottom left
Application Field
❖ Architectural surveying ❖ Vehicle alignment and four-wheel calibration
❖ Road and slope gradient detection ❖ Medical equipment attitude measurement
❖ Tooling & fixture leveling and control ❖ Camera pan-tilt angle calibration
❖ Mechanical equipment installation and leveling ❖ Pipeline laying and angle control
Specifications
|
GDS850 |
Parameter |
Unit |
|
Angle Measurement Range |
±30 |
° |
|
Measuring Axis |
Single axis |
|
|
Maximum Measurement Accuracy |
<0.002 (＜5°) <0.003 (5°-30°) |
°(RMS) |
|
Angle Measurement Resolution |
0.0005 |
° |
|
Measurement Mode |
degrees, millimeters/meters Two modes can be set |
/ |
|
LCD |
64-color true-color luminous display screen |
/ |
|
LCD Viewable Area Size |
L60*W45 |
mm |
|
Operating Temperature |
-10°~ +70℃ |
°/℃ |
|
Operating Humidity |
85 |
%RH |
|
Power Supply |
2A AA batteries |
/ |
|
Battery Continuous Working Time |
6 |
h |
|
Vibration Resistance |
10g@11ms, triaxial (half-sine wave) |
g |
|
Shock Resistance |
10grms / 10~100Hz |
g |
|
Weight |
1200g |
g |
|
Waterproof Rating |
IP54 |
/ |
|
Material |
Anodized aluminum alloy |
/ |
|
Dimensions |
L140*W140*H45mm |
mm |
Product Dimensions
Housing: 140×140×45mm
